Tenda Switch 9 Port Gigabit PoE ( 102W ) \ TEG1109P

TEG1109P

TEG1109P

The TEG1109P is another switch from Tenda, specifically designed for users who need a more robust and faster network solution, particularly in environments requiring Gigabit Ethernet.

• 9-Port Gigabit Ethernet Switch:

  • The TEG1109P features 9 ports, with 8 of them being 10/100/1000Mbps Gigabit RJ45 ports that support Power over Ethernet (PoE), and 1 uplink port without PoE capability.

• Power over Ethernet (PoE):

  • The switch is equipped with 8 PoE ports, compliant with both IEEE 802.3af and IEEE 802.3at standards. This allows the switch to deliver up to 30W per port, making it suitable for powering high-power devices such as IP cameras, VoIP phones, and high-performance wireless access points.

  • The total power budget for PoE is up to 120W, which is ample for powering multiple high-power devices simultaneously.

• Gigabit Speeds:

  • All 8 PoE ports support Gigabit speeds, ensuring that the connected devices can communicate at high data rates. This is crucial for applications like HD video surveillance, where large amounts of data are transmitted.

• Extended Transmission Distance:

  • The TEG1109P supports data and power transmission up to 250 meters in extend mode, which is beneficial for scenarios that require long-distance deployments.

• Surge Protection:

  • The switch is designed with 6KV surge protection, safeguarding the device and connected equipment from electrical surges and lightning, particularly in outdoor or industrial installations.

• VLAN Support:

  • The TEG1109P includes a VLAN mode that can isolate ports 1-8 from each other, while allowing communication with the uplink port. This helps enhance network security by preventing unwanted traffic between connected devices and reducing the risk of broadcast storms.

• Plug and Play:

  • Like other switches in Tenda’s lineup, the TEG1109P is a plug-and-play device, meaning it requires no complex configuration. It’s easy to install and deploy, making it suitable for users without extensive networking knowledge

TEG1109P

• Use Cases:

  • The TEG1109P is ideal for small to medium-sized businesses, surveillance systems, and SOHO (Small Office/Home Office) networks that require high-speed Gigabit connectivity and PoE support for devices such as cameras and access points.

Technical Specifications:

• Ports:

  • 8 × 10/100/1000Mbps PoE RJ45 ports

  • 1 × 10/100/1000Mbps uplink RJ45 port

• PoE Standard:

  • IEEE 802.3af/at

• PoE Power Budget:

  • 120W total PoE power

• Transmission Distance:

  • Up to 250 meters in extend mode

• Surge Protection:

  • 6KV

• Dimensions:

  • Compact design suitable for desktop or wall-mount installation.

• 9 ports with 8 supporting PoE at Gigabit speeds

• 120W PoE power budget for powering multiple devices

• Supports extended transmission up to 250 meters

• 6KV surge protection for enhanced durability and safety

• VLAN support for improved network security

• Plug and play for easy setup
